TracTuff Remote Oil Filter Mount

The TracTuff Remote Oil Filter Mount is a universal product designed to relocate the oil filter to a more convenient location.

The remote oil filter mount was designed around the popular Honda S2000 oil filter and uses a Genuine Honda M20 x 1.50 mounting stud. If you dont own a Honda or if you have a favorite size and brand... all you need to do is make sure it has an M20 x 1.50 thread and a gasket bigger than 2.25"(57.15mm ) and a max body diameter of 3.15" (80mm). If you are looking for a larger oil filter mounting solution... check out the XL Remote Oil Filter Mount.

The assembly can be mounted in any direction, even upside-down, due to the mounts unique raised lip around the filter that helps contain the oil when the filter is changed. The oil filter mount has machined “IN” & “OUT” markings and accepts -10 ORB fittings. The mounts also has a filtered 1/8" NPT accessory port to add a sensor or supply clean oil to an accessory. The hardware kit includes 1/8" NPT plugs and stainless steel mounting bracket to filter mount hardware.

NOTE: If you don't already have an adapter to get the oil from the original filter location to your new remote mount location... I have equally well thought out solution, please be sure to check it out. If you are choosing NOT to buy the port fittings... please be sure to purchase fittings that have max hex size of 1.15" or they wont work or will need to be turned down. I also highly suggest the use of a one-way check-valve on the plumbing of the line feeding this product with oil, as close to the source as possible.

I recommend at least a 3.00" x 4.00" flat surface for the triangle mounting foot and 8.00" of space for oil filter removal and fittings.
